CLR
‧Measuring principle: dual-wavelength colorimetric absorption with automatic turbidity compensation, reported in Hazen. ‧Housing: 316L stainless steel, corrosion resistant. ‧RS-485 digital interface with standard Modbus RTU. ‧Reagent-free, no secondary pollution, for online monitoring. ‧On-site calibration by standard solution or water sample. ‧Built-in wiper stops fouling; interval is adjustable. ‧Measures and outputs water temperature simultaneously. ‧IP68 rated, CNS 14165 tested for long-term submersion.
–Applications–
Rivers, reservoirs, raw water, effluent and environmental monitoring.
Download
Center
Optional Code & Specifications
-RS485 type-
CLRCode 1
NN
| Code 1 | Sensor Cable | Code 1 | Sensor Cable |
| 10N | 10 m + Bare Wire | 10C | 10 m + Quick Conn. |
| Value N | Length + Bare Wire | Value C | Length + Quick Conn. |
※RS485 Type: Code 2 and Code 3 are fixed at N
| Principle | Dual-wavelength method | |||||
|---|---|---|---|---|---|---|
| Range | 0.1~30 Hazen | |||||
| Resolution | 0.1 Hazen | |||||
| Temp. Range | 0°C～50°C | |||||
| Accuracy | ±5% | |||||
| Temp. Acc. | ±0.5°C | |||||
| Max. Press. | 0.1MPa | |||||
| Calibration | Std. solution / sample | |||||
| Interface | RS-485 Modbus RTU | |||||
| Power | 9~36VDC | |||||
| Weight | 1.1kg (with 10 m cable) | |||||
| Dimensions | Ø32*189mm | |||||
| Protection | IP68 (CNS 14165) | |||||
| Housing | 316L stainless steel | |||||
-Wi-Fi type-
CLR - Code 1 - Code2 - W
| Code 1 | Sensor to Wi-Fi Box | Code 2 | Wi-Fi Box to Host |
| 10N | 10 m + Bare Wire | 3N | 3 m + Bare Wire |
| 3C | 3 m + Quick Conn. | ||
| 10C | 10 m + Quick Conn. | 10N | 10 m + Bare Wire |
| 10C | 10 m + Quick Conn. | ||
| Value N | Length + Bare Wire | 20N | 20 m + Bare Wire |
| 20C | 20 m + Quick Conn. | ||
| Value C | Length + Quick Conn. | ValueN | Length + Bare Wire |
| ValueC | Length + Quick Conn |
| Principle | Dual-wavelength method | |||||
|---|---|---|---|---|---|---|
| Range | 0.1~30 Hazen | |||||
| Resolution | 0.1 Hazen | |||||
| Temp. Range | 0°C～50°C | |||||
| Accuracy | ±5% | |||||
| Temp. Acc. | ±0.5°C | |||||
| Max. Press. | 0.1MPa | |||||
| Calibration | Std. solution / sample | |||||
| Interface | RS-485, Wi-Fi web | |||||
| Power | 9~36VDC | |||||
| Weight | 1.1kg (with 10 m cable) | |||||
| Dimensions | Ø32*189mm | |||||
| Protection | IP68 (CNS 14165) | |||||
| Housing | 316L stainless steel | |||||
